8H GTE HYBRID

YOUR PRODUCTIVITY
AT The NEXT LEVEL.

The Logset 8H GTE Hybrid is a powerful medium-sized harvester that doesn’t slow down under pressure. The machine´s diesel engine runs at a constant pace, while the hybrid system provides up to 104 kW (142 hp) of additional power required in a typical felling and processing cycle. This allows the hybrid harvester to easily perform several tasks at the same time, while keeping the engine load constant.

technologies

technologies

HYBRID TECHNOLOGY IN FOREST MACHINES?

The diesel engine runs at a static ~1500 rpm. The electric motor handles the peaks in power. No need for constant rpm changes. You get more power, lower fuel consumption, lower CO2 emissions and less noise. Less stress, for the machine and the pilot.

HIGH POWER, LOW CONSUMPTION

ACGO Power 7.4 liter diesel engine gives plenty of power together with the 104 kW electric motor. Our philosophy is to have lots of power in stock, but to use it wisely. Logset machines are the most fuel-efficient forest machines on the market. With Logset, you get the most out of every fuel liter you use. And more importantly, you always have power for all tasks when needed.

EVERYTHING FOR USER EXPERIENCE

Your machine is as good as it feels. Our cabin has good reputation with great visibility, lots of space and low noise levels. Controls can be configured to suit every driver’s needs. TOC MD2 keeps you on track with all necessary information.

Good balance, great flotation, enough power for multiple simultaneous tasks.  All simple, basic things for the pilot to succeed all day long. And we know, the day can be really long!

ADVANCED TECHNOLOGY

Logset forest harvesters are a phenomenal example of modern technology. Heavy-duty steel combined with 150 000 – 200 000 rows of code plus the latest electrical and hydraulic innovations. Everything is made for maximum production with reasonable amount of driver effort.  All in a robust steel shell that is built to last and produce.

8h gte hybrid

in a nutshell

tech specs

Own weight, from23 000 kg (50 700 lbs)

Max. power at 1850 rpm311 kW (422 hp)
Max. torque at 1500 rpm1 780 Nm (1 313 ft lb)

TypeAGCO Power 74 LFTN
StageEU Stage V, EPA Tier 4 final
Power at 1850 rpm214 kW (291 hp)
Torque at 1500 rpm1 280 Nm (944 ft lb)
Fuel tank, net390 l (103 US gal)
DEF40 l (10 US gal)

Max. power at 1850 rpm97 kW (132 hp)
Max. torque 0-1950 rpm500 Nm (369 ft lb)

TypeHydrostatic mechanical
Tractive effort195 kN (43 800 lbf)
Gear box2 gears

Flow 1 000 rpm210 + 180 l/min (55 +47 US gal)
Hydraulic oil tank, net195 l (52 US gal)

Control SystemTOC 2
Measuring deviceTOC-MD 2
Battery voltage24 V

Safety tested and approved cabin +
Rotating and levelling cabin

Front710/45-26.5 (600/55-26.5, 800/40-26.5 optional)
Rear710/45-26.5 (600/55-26.5, 800/40-26.5 optional)
CraneMesera 241 H
Lifting capacity240 kNm (177 000 ft lb)
Reach options10,3/11,1 m (33.8/36.4 ft)

Model optionsTH55, TH65, TH75


Contact your local dealer for more information about options.

features

features

FORWARDER CABIN

One of the most spacious cabins on the market. A sleek and simple design built with maximum visibility and usability in mind. By the way, ..

STRONG BODY FOR STRONG PEOPLE

Logset machine chassis is heavily based on the original design from the 90’s. It was built to be the most durable machine of the woods. ..

CABIN TILT & ROTATION

The harvester cabin adjusts with the differences in terrain so you will always sit nice and straight. The adjustable cabin rotation allows you to have ..

LET THERE BE LIGHT!

You cannot see what you don’t see. An optimal light field together with wide visibility from a Logset cabin gives you stress-free and better work ..

Custom controls

You can customize many of our controls to suit your needs. No need to search buttons, just place them as you want.

Crane tilt

Crane tilt is a very usable option when working on demanding terrain.

TOC-MD 2

Logset machines are operated and controlled by our advanced control system TOC-MD 2.

MAINTENANCE IN MIND

Logset machines is built to keep in good shape. Several advanced solutions keeps Logset service easy: Component and servicepoints are placed for maintenance in mind. ..

AGILE IS MY NAME

Logset harvesters are very agile. The wheels follow sharply in the tracks, and even tight turns are possible to make with great balance. Good agility ..

CABIN DOOR CLOSE AID

A simple, but good gadget: Your cabin door can be opened/closed with one finger. The pneumatic door closing handle is handy when working on windy ..

LOW FUEL CONSUMPTION

All the power you need, with low fuel consumption. Our machines have plenty of power to use wisely. All for making it easy for the ..
